AP Heavy Duty Offset Discs

AP Discs are most popular for heavy workloads and tough conditions. Offering excellent strength, value for money, long service life and a level finish.

Tough worker

  • Efficient primary and secondary cultivating with 90+Hp
  • Hydraulic cut standard (manual cut optional)
  • Hydraulic front to back levelling for contour following
  • Level finish in all conditions
  • Swivel hitch
  • Standard with Ø660mm or Ø710mm blades, 6mm thick (7mm or 8mm optional)
  • 40mm axle (50mm optional) with big triple sealed tapered roller bearings – so easy maintenance.
  • Optional rear drawbar and road lights

Gallery

1 / 6

Technical Specifications

Model

Working width

Weight approx.

No. discs

Disc size

Disc spacing

Cut

HP Required

AP 26-66-23

2.95m

2850kg

26

660mm(26in)x6mm

230mm(9in)

Hydraulic

90+

AP 28-66-23

3.15m

2950kg

28

660mm(26in)x6mm

230mm(9in)

Hydraulic

100+

AP32-66-23

3.60m

3200kg

32

660mm(26in)x6mm

230mm(9in)

Hydraulic

120+

AP26-71-26

3.15m

3350kg

26

710mm(28in)x6mm

260mm(10in)

Hydraulic

120+

AP28-71-26

3.55m

3500kg

28

710mm(28in)x6mm

260mm(10in)

Hydraulic

120+

Get a free consultation and demo



Testimonials

Brendon says the rocky terrain is hard on gear but the discs have Brendon’s endorsement.

“They’re really, really good – they’re robust and simple to use. They were pretty competitively priced too.

They dig in well and leave a nice, level finish. We’re getting a good depth out of them.”

APL Offset Discs | Customer Testimonial – Brendon Hargest
